38mm Pin Wrench for Evinrude E-TEC 75–115hp Single-Cylinder Trim, L-4/L-6 Pins

Remove and install the trim/tilt cylinder cap on Evinrude E-TEC 75–115hp outboards with the single-cylinder trim unit. The K1010 is our patented 300 Series 38mm Pin Wrench (AMT0304) with two pin sets: its six L-4 pins, plus six heavy-duty L-6 pins for the E-TEC cap. It does the same job as Evinrude tool 0352932.

Its hex body fits the Pin Wrench Sleeve (AMT0170): slide the sleeve over the wrench, lower the outboard onto it, and the motor's weight holds the wrench flat in the cap so it can't kick out. The body is polished stainless steel with a 1/2" square drive, and the pins are rated to at least 200 ft-lb. Backed by the Marine Tech Tools lifetime warranty.

Reference part numbers: 0352932

Fits These Motors

• Evinrude E-TEC 75–115hp with single-cylinder trim/tilt

Not sure which one fits? Use the selector at the top of the trim/tilt wrench category page.

Specifications

• Pin stance: 38mm
• Pins: six L-4mm and six L-6mm, replaceable
• Drive: 1/2" square
• Torque rating: 200 ft-lb minimum
• Body: polished stainless steel

What's Included

• 38mm x 4mm Pin Wrench (AMT0304) — 300 Series body with six L-4 pins. Also sold on its own.
• Six L-6mm pins for the E-TEC cap

Works With

• Pin Wrench Sleeve (AMT0170) — locks the wrench in the cap
• Replacement Pins, L-6mm, set of 6 (AMT0011)
• Replacement Pins, L-4mm, set of 6 (AMT0050)
• Tilt Piston Wrench, BRP T-553 Replacement (AMT0140)
• Tilt Piston Wrench, BRP T-552 Replacement (AMT0145)
• Trim and Tilt Impact Tool (AMT0012) — for caps a pin wrench can't break loose
